1.Manufactured by our enterprise.

2.Riveted structure is adopted to connect the cylinder body and back cover, and piston and piston rod to make it compact and reliable.

3.Free mounting cylinder, whose free space can be applied on many kinds of working occasion.

4.The seal of piston adopts heterogeneous two-way seal structure. It has compact size and has the function of oil reservation.

5.The cylinder body has stainless steel pipes with high precision to produce high strength and corrosion resistance.

6.There are cylinders and mounting accessories with several specifications for your choice.

1.When load changes in the work the cylinder with abundant output capacity shall be ed.

2.Relative cylinder with high temperature resistance or corrosion resistance shall be chosen under the condition of high temperature or corrosion;

3.Necessary protection measure shall be taken in the environment with higher humidity much dust or water s oil dust and welding dregs.

4.Dirty substances in the pipe must be cleared away before cylinder is connected with pipeline to prevent the entrance of     particles into the cylinder.

5.The medium used by cylinder shall be filtered to 40μm or below.

6.As both of the front cover and piston of the cylinder are short typically too large stroke can not be ed.

7.Antifreezing measure shall be adopted under low temperature environment to prevent moisture freezing.

8.The cylinder shall avoid the influence of side load in operation maintain the normal work of cylinder and extend the service life.

9.If the cylinder is dismantled and stored for a long time pay attention to conduct antirust treatment to the surface. Antidust caps shall be added in air inlet and outlet ports.
